In the current market context of increasingly diversified and sophisticated logistics and transportation, an efficient, economical and reliable light truck has become the first choice for many small and medium-sized enterprises, individual entrepreneurs and professional transportation companies. The SM200 light truck is such a product that integrates power performance, loading capacity, safety and adaptability. With excellent technical configuration and reasonable design solutions, it provides users with all-round protection and convenience during transportation.
This article will comprehensively introduce the main configuration, performance characteristics and advantages of the vehicle to help users better understand its value.
This light truck mounted water well drilling rig is equipped with a Yuchai YC4102 engine or a Yunnei 116 horsepower engine (Euro II emission standard). Both power systems have been verified by the market for many years and have excellent fuel economy and reliability. Its power coverage is moderate, which can effectively meet the needs of multiple scenarios such as urban distribution, rural logistics, and short-distance transportation. Whether in congested urban roads or complex rural roads, the vehicle can output power stably to ensure the smooth completion of transportation tasks.
The engine adopts mechanical injection technology, which is easy to maintain, has a high universal rate of accessories, and low maintenance costs. For start-up users or corporate users with high transportation frequency, this economy is particularly important and can significantly reduce daily operating costs.
The water well drilling rig truck mounted is equipped with a Wanliyang (WLY) gearbox, which supports 6 forward gears and 1 reverse gear. The gear shifting logic is clear, the gear ratio setting is reasonable, and it takes into account the needs of low-speed starting and high-speed cruising. Under normal load conditions, the gearbox can achieve a balance between power and speed and effectively reduce fuel consumption.
In addition, the gearbox has a mature structure, stable quality, and a long maintenance cycle. It is suitable for frequently used logistics operation scenarios and is one of the transmission systems with an excellent reputation in the industry.
The truck adopts a combination of a 2.4-ton front axle and a 4.2-ton rear single drive axle, with a rear axle speed ratio of 5.83, which has strong load-bearing capacity and traction, suitable for medium to short distance cargo transportation tasks. Combined with the leaf spring suspension system, using a multi leaf spring steel plate structure can not only effectively alleviate road impact, but also enhance the stability of the vehicle under heavy load, ensuring transportation safety.
Especially in unpaved road environments such as rural and mountainous areas, this chassis system can greatly improve the vehicle's passability and adaptability, and reduce transportation risks.
This car is equipped with a drum brake system, which is structurally stable, easy to maintain, and suitable for various road conditions. In terms of braking system, it is equipped with a triple safety mechanism of air pump braking, exhaust braking, and parking braking. The air pump brake provides sufficient braking pressure, the exhaust brake effectively assists in deceleration when going downhill, and the parking brake ensures the safety of the vehicle in a stationary state. The synergy of the three greatly improves the overall safety performance of the vehicle.
At the same time, the cab is equipped with a dual seat belt structure, locking system, and seat belt limiter, effectively ensuring the personal safety of the driver and passengers during driving.
The domestic steering gear with hydraulic power system makes the steering wheel operation easier, and can easily cope with complex operations such as frequent turns and reversing, significantly reducing the driver's fatigue. The left-hand drive adapts to domestic traffic regulations and improves driving convenience.
Although the car has a single-row cab, no berths and air conditioning, its interior space is reasonably designed, spacious and bright. Equipped with an MP3+USB entertainment system, it adds a relaxing atmosphere for long-term driving. At the same time, the manual split lifting cab is used to facilitate engine inspection and maintenance.
This light truck mounted borehole drilling machine is equipped with 7.50R16 steel wire tires and 6+1 (including spare tire) configuration to ensure sufficient emergency support during long-distance driving. Steel wire tires have better wear resistance and grip, and can maintain good stability even in wet or complex terrain.
This light truck drilling machineEquipped with 2 75AH batteries (24V system), it can meet the stable operation of engine starting, onboard electrical appliances and lighting. The 120L large-capacity fuel tank can effectively reduce the frequency of refueling and improve operational efficiency in daily operations.
With the negative grounding design, the circuit system is simple, maintenance is convenient, and the electrical failure rate is reduced.
customize
We can provide customized painting services by choosing different colors according to customer needs. Special colors require an appropriate surcharge to meet personalized needs such as brand promotion and company logo unification. The vehicle delivery cycle is 40 working days, and the production and logistics processes are stable to ensure timely advancement of customer project nodes.
hydraulic 200m well drilling machine mounted drilling truck diesel water well drilling rig for sale are cost-effective transportation vehicles that combine practicality, economy, and safety. It exhibits a balanced performance in terms of power output, load capacity, handling experience, and transportation convenience, making it particularly suitable for individual transportation operators, small and micro enterprises, rural logistics, and export customers.
If you are looking for a light truck that can meet daily transportation tasks while also considering usage costs, the SM200 would be your ideal choice.
SM200 Light truck mounted vehicle
|
整机重量(T) The weight |
9.5 |
主机功率(kw) Equipped capacitor |
Yuchai 58KW |
|
钻杆直径(mm) Drill pipe diameter |
Φ76 Φ89 |
钻杆长度(m) Drill pipe length |
1.5/2.0/3.0 |
|
钻孔直径(mm) The hole diameter |
140-254 |
钻孔深度(m) Drilling depth |
200 |
|
一次性推进长度(m) One-time advance length |
3.6 |
进尺效率(m/h) The penetration efficiency |
10-35 |
|
回转速度(rpm) Swing speed |
45-70 |
回转扭矩(N.m) Swing torque |
3500-4800 |
|
提升力(T) Rig lifting force |
13 |
卷扬机提升力(T) Hoisting force of winch |
1 |
|
快升速度(m/min) Rapid rise speed |
20 |
快进速度(m/min) Fast feeding speed |
40 |
|
工作气压(MPA) Using air pressure |
1.7-2.5 |
耗气量(m³/min) Air consumption |
17-31 |
|
行走速度(km/h) Walking speed |
0-80 |
爬坡能力(Max.) Climbing angles |
25 |
|
装车宽度(m) Width of loading |
/ |
尺寸(mm) Dimension |
6500×2150×2450 |
