This month, a customer from France bought an Atlas Copco Xas 88 portable diesel air compressor from D Miningwell to power mining projects, which can be used with YT27/28/29A rock drills. The customer is very satisfied with our service and quotation.
Fantastic 8 series
The 8 series atlas copco diesel compressor is a new product from Atlas Copco. Its most distinctive feature should be its high efficiency and portable, lightweight size. The Atlas Copco Xas 88 is powered by a diesel engine from a well-known brand such as Kubota, Deutz or Honda, and produces up to 5.3m³/min of air, with a robust rotary configuration that ensures powerful and reliable performance in demanding environments. The Xas88 diesel compressor has a new design that is more compact, with dimensions of 2000 mm x 1200 mm x 1200 mm, and weighs less than 750 kg, a 15% reduction in volume; it is equipped with Atlas Copco's new generation of air compressor heads, which reduces the oil consumption of the compressor by 12%. When not using electricity, the energy saving system automatically reduces the engine speed to minimize fuel consumption.
In addition, atlas copco diesel compressor can provide both electric and air power, so you can choose it when you need to power a light truck, power tools, small electric equipment, for all up to 400V power needs, without the need to prepare a separate generator. The 8 series atlas copco diesel compressor can be equipped with an optional integrated generator. Protected by a helmet, the integrated power source can provide up to 5.3m³/min air power and 400V electricity.
| model | XAHS 38KD | XAS 58KD | XATS 68KD | XAS 78KD | XAS 88KD | XAS 98KD | XAS 98KDG | |
| Working pressure |
bar (g) |
12 | 7 | 7 / 10.3 | 7 | 7 | 7 | 7 |
| Volumetric Flow | m³/min | 2.3 | 3 | 3.5 | 4.5 | 5 | 5.3 | 5.3 |
| Oil volume | L | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
| venting valve | Quantity Size | 3*3/4″ | 3*3/4″ | 3*3/4″ | 3*3/4″ | 3*3/4″ | 3*3/4″ | 3*3/4″ |
| ultimate temperature | ºC | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Minimum starting temperature | ºC | -10/-20 | -10/-20 | -10/-20 | -10/-20 | -10/-20 | -10/-20 | -10/-20 |
| static | dB(A) | 101 | 101 | 101 | 101 | 101 | 101 | 101 |
| Engine | ||||||||
| model |
V 1505 |
V 1505 |
V 1505 T |
V 1505 T |
V 1505 T |
V 1505 T |
V 1505 T |
|
| branding | Kubota | Kubota | Kubota | Kubota | Kubota | Kubota | Kubota | |
|
Number of cylinders |
4 | 4 | 4 | 4 | 4 | 4 | 4 | |
| Power | kW | 26.5 | 26.5 | 26.5 | 33 | 33 | 33 | 33 |
|
Nominal speed |
rpm | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 |
| Unload speed | rpm | 1800 | 1800 | 1850 | 1850 | 1850 | 1850 | 1850 |
| Capacity | ||||||||
|
Engine oil |
L | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 |
|
Compressor oil |
L | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
|
Fuel tank capacity |
L | 60 | 60 | 60 | 60 | 60 | 60 | 60 |
Perfect after-sales service
With a comprehensive 1-year warranty and overseas service options, Atlas Copco ensures reliable support and service continuity, boosting customer confidence in their investment. Prior to shipping each atlas copco diesel compressor is securely packed on a wooden pallet for consolidation or full crate shipment, ensuring safe transportation and minimizing the risk of damage during transit. In addition, as a screw air compressor manufacturer, our customer service is online 24 hours a day to receive your after-sale inquiries in time and solve your problems as fast as possible. So you don't need to worry about after-sale problems. This is one of the reasons why customers choose us.
